EP400 OB ATEX

Handheld UHF ON BOARD radio – Novelradio EP400 OB ATEX

INTRINSICALLY SAFE
ATEX: II 2G Ex ib IIC T4 Gb
IECEx: Ex ib IIC T4

Approval N°0014737-352755









  • Pocket size, light, rugged, reliable
    •
  • 255 Channels
    •
  • Ex-ATEX Li-ion battery
    •
  • Programmable function keys
    •
  • Individual or group call
    •
  • Save battery mode
    •
  • MIL STD 810F
  • EN 300-720-2 ON BOARD certificated
    •



FEATURES AND SPECIFICATIONS

General
Frequency 450 – 470 MHz (UHF)
Channel spacing 12,5 – 25 KHz
Battery Li-Ion 7.4V / 1300mAh, ATEX II 2G Ex ib IIC T4 Gb
Battery life 10 hours with 5/5/90 profile
Microphone Internal, condenser
Dimensions 54 (W) x 114 (H) x 30 (D) mm
Weight 285 gr
Package content Handheld radio, Li-ion battery, charger, belt clip, antenna and user manual
Receiver and audio
Sensitivity (12dB SINAD) < 0,25µV
Channel selectivity > -60 / -70 dB
Audio power 1W
Audio distortion < 5% a 1KHz
Transmitter
RF power 2W
Spurious emission < -36 dBm
FM noise < -40 dB
Audio distortion < 5% a 1KHz
Accessories
A-BP-5 1300mAh Li-Ion battery
A-CH-9 Charger 110-220Vac
NR-73 UHF flexible antenna for EP-400
A-MS-12 External MIC/Speaker
NR-68 USB cable and programming SW

DOCUMENTS

Datasheet Novelradio EP400 OB

User manual Novelradio EP400 OB
